Cantonk 1080P 4ch ahd cctv kit with 4 camera bullet cantonk 1080p security camera system

FOB Reference Price:Get Latest Price
US $60-80 / Set | 1 Set/Sets (Min. Order)
Supply Ability:
15000 Set/Sets per Day
Port:
Guangzhou/Shenzhen
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Guangdong, China (Mainland)
Brand Name:
Cantonk
Model Number:
XVRD420RF20
Product name:
Cantonk 1080Pp h.264 4ch ahd cctv kit with 4 camera bullet
Camera:
4 pcs bullet camera
Chip solution:
H62+HTC960E
XVR:
H.264 4CH
IR Range:
20m
Resolution:
2mp
Certificate:
CE/FCC/ROHS/ISO9001:2008
Warranty:
2 years
Vidieo Output:
1xHDMI /1xVGA /1xCVBS
Keyword:
cctv camera
Packaging & Delivery
Packaging Details
Cantonk or OEM package as customer request
Delivery Time
7 days after your payment

Cantonk 1080Pp h.264 4ch ahd cctv kit with 4 camera bullet

Product Description
*DIY Video Input: HD includes AHD, HD-CVI, HD-TVI
HD: Max 4CH@15fps / IPC: Max 9CH@30fps / Analog: Max 4CH@30fps
*Video Output: 1xHDMI /1xVGA /1xCVBS
*Audio Input/Output: RCA 4CH In/ 1CH Out
*Compression Method: H.264
*HD: 1080N/720P, PAL every channel 1fps-15fps adjustable;
NTSC every channel 1fps-15fps adjustable;
Analog: 960H, PAL every channel 1fps-25fps adjustable;
NTSC every channel 1fps-30fps adjustable;
IPC: 1080P/960P/720P (Total incoming bandwidth ≤46M),
PAL every channel 1fps-25fps adjustable; NTSC every channel 1fps-30fps adjustable;
*Preview resolution: 1080P/720P
*Playback: Support single channel mode.
*Hexaplex operation simultaneously: Live, Recording, Playback, Network Operating
*Static, Dynamic IP and DDNS, P2P, Support IE and Special CMS
*2×USB ; 1xRJ45(10M/100M adaptive Ethernet interface)
*1 SATA Hard Disk Interface (2.5"/3.5" SATA, Up to 6TB)
*Backup: USB2.0 (such as U disk, USB Drive) and network
*Support remote view by Mobilephone (iPhone, iPad, Android Phone)
*DC 12V ≤18W (with adaptor, with 1x1TB Seagate hard disk ST1000VM002)
*DVR Dimension (L×W×H): 260*215*43(mm)
**Weight of Kit Package CP20: 5.77kgs, Weight of Kit Package R25: 6.85kgs






Product Images



Packaging & Shipping



Company Information

Why choose us?

1.14 years experience in exportation all over the world

2.2000 Employees, 50000 Square Meters,20 Production Lines

3.Passed CE,FCC,ROHSand  ISO9001:2008 certificate!
4.Our own SMT Production line,housing and mould factory

5. 2 years warranty

6.5 times QC testing
7.OEM,ODM service

Factory Photo:



Who we are?

"Reliable Digital Security Solution Provider"

Cantonk Corporation Limited is a leading and professional CCTV manufacturer extablished in 2003 in Guangzhou, China. We specialize in researching, producing and exporting CCTV Cameras and Stand-alone DVRs, providing the most stable digital security solutions. Till now our product range has covered HD-IP Cameras, HD-SDI Cameras, Indoor and Outdoor cameras, PTZ Cameras, NVRs and DVRs more than 650 models. We are willing to make all of our employees be happy in working for Cantonk and make all of our reliable customers be successful in cooperation with Cantonk.

To strengthen our brand CANTONK, we have done a series of improvements: We have started to use ERP system to control our whole factory operations to make every process be standard; we have passed ISO9001:2008 to get our quality control be systematized; we have built up our own housing factory to design new products to get high competition; We have well-trained our employees to have high work efficiency. Now our production output reaches 150000pcs/per month, and our sales amounts in 2013 are twofold of 2012. Our target in 2014 is twofold of 2013 onsales amounts.

Technology Innovation, Absolute-advantage CCTV products, Considerate Customer Service are our direction of continuing fighting. Cantonk would liketo express “safety, warmness, and positive to the world”.

Welcome your visiting Cantonk in 2017!







Certifications





Our Services

ODM & OEM Service

1. LOGO
Three requirements need to be satisfied at the same time for Customers' Logo printing:
a. Quantity for each models need be more than 10pcs
b. Quantity for all models need be more than 50pcs
c. Logo should be One or Two colors only, and we need high resolution clear logo in JPG format.

Otherwise you can add USD 30 as LOGO printing fee.

2. Label
Please send us your own model number, serial or barcode numbers, and also the special designs if required.

3. User manual
We can put only customers' model number on the user manual by free of charge. If you have special requirement, please provide the finished manual file that can be printed directly.

4. Color Box
Design your own style based on the design file we provided, and then send it back to us. Samples
will be sent to you for checking before mass production

5.  Free ODM
Our New MOLD FACTORY is waiting for your new design and new innovation.

FAQ
* How to buy from us?

1.  Please confirm the model numbers and quantities that you would like to purhcase with Ms Niki.


2.  We will send you a Proforma Invoice once we get your order, and will help you calculate the best freight charge by courier, by air or by sea if required.


3.  After your send us the payment, please provide the bank copy if possible, so that we can start to arrange production.

4.  As soon as the goods is shipped out, we will let you know the tracking number.

* Conditions

1. MOQ

No limite on the first purchase; 10 pcs after sample order.



2. Payment term: T/T, Paypal and L/C for option

a. By T/T: Bank transfer to Cantonk company bank account
b. By Paypal: There will be 4% of total price as paypal fee
c. By L/C(letter of credit): the order is more than USD20,000.00


3. Lead time
a. 7 Days after payment arrived, for sample order less than 15PCS
b. 10-14 Days after payment For a formal order





* Warranty

All of our products are 100% passed strictly quality inspection before delivery.



We provide Two years warranty for CCTV Camera and One year for DVR after the shipment date.


1, For the products that prove defective under normal usage, if our customers could repair the products by themselves,  we will supply the spare parts.


2.  If the customers couldn't repair the products, the products need to be shipped back to us. We repair and afford 50% of  freight charge.


3.  If the products are broken by violence, carelessness, repaired or altered without the authorization, we will not be responsible for the warranty.


To return a product for repair, please talk to our sales person for an RMA instruction.  Thank you.
